制备方法对CuZnAl-ZrO<sub>2</sub>双功能催化剂合成气制C<sub>4</sub>烃类性能的影响

瞿凡; 殷富; 魏宇学; 孙松; 王飞; 常强; 张成华

doi:10.12434/j.issn.2097-2547.20240492

您当前的位置：

首页 >

文章列表页 >

制备方法对CuZnAl-ZrO₂双功能催化剂合成气制C₄烃类性能的影响

C1化学与催化转化 | 更新时间：2025-09-26

- 制备方法对CuZnAl-ZrO₂双功能催化剂合成气制C₄烃类性能的影响
- Influences of preparation methods on performances of CuZnAl-ZrO₂ bifunctional catalysts for producing C₄ hydrocarbons from syngas
- 低碳化学与化工 2025, 50(9): 1-9.
- 作者机构：

  1.安徽大学化学化工学院，安徽合肥 230601
  2.中国科学院山西煤炭化学研究所，山西太原 030001
  3.中科合成油技术股份有限公司国家能源煤基液体燃料研发中心，北京 101407
- 作者简介：

  瞿凡（1999—），硕士研究生，研究方向为多相催化，E-mail：qf88882022@163.com。
  常强（1989—），博士，高级工程师，研究方向为多相催化，E-mail：changqiang12@mails.ucas.ac.cn；
  张成华（1975—），博士，教授级高级工程师，研究方向为多相催化，E-mail：zhangchh@sxicc.ac.cn。
- 基金信息：

  国家重点研发计划(2022YFB4101204);国家自然科学基金(22302219;22179001;22308001;21902001);安徽省高校杰出青年科研项目(2022AH020007);安徽省高校协同创新项目(GXXT-2023-009);安徽省高等学校自然科学基金(2023AH050114)
- DOI：10.12434/j.issn.2097-2547.20240492
  中图分类号： TQ426;O643.36
- 收稿日期：2024-12-13，

  修回日期：2025-01-12，

  纸质出版日期：2025-09-25
- 稿件说明：
移动端阅览
瞿凡,殷富,魏宇学等.制备方法对CuZnAl-ZrO₂双功能催化剂合成气制C₄烃类性能的影响[J].低碳化学与化工,2025,50(09):1-9.

QU Fan,YIN Fu,WEI Yuxue,et al.Influences of preparation methods on performances of CuZnAl-ZrO₂ bifunctional catalysts for producing C₄ hydrocarbons from syngas[J].Low-Carbon Chemistry and Chemical Engineering,2025,50(09):1-9.
瞿凡,殷富,魏宇学等.制备方法对CuZnAl-ZrO₂双功能催化剂合成气制C₄烃类性能的影响[J].低碳化学与化工,2025,50(09):1-9. DOI： 10.12434/j.issn.2097-2547.20240492.

QU Fan,YIN Fu,WEI Yuxue,et al.Influences of preparation methods on performances of CuZnAl-ZrO₂ bifunctional catalysts for producing C₄ hydrocarbons from syngas[J].Low-Carbon Chemistry and Chemical Engineering,2025,50(09):1-9. DOI： 10.12434/j.issn.2097-2547.20240492.

摘要

异构合成是由合成气（CO + H

）直接合成异丁烯和异丁烷的反应，目前该反应主要使用ZrO

基催化剂，但反应条件普遍较为苛刻，并且催化剂的CO转化率和C

烃类选择性均较低。为了解决单一ZrO

活化CO生成C1物种性能较弱的问题，对CuZnAl催化剂与ZrO

耦合形成的双功能催化剂进行了研究。分别以共沉淀法、浸渍法和物理混合法制备了双功能催化剂，并对其织构性质、氧化物质量分数和晶相结构等进行了表征。在合成气组成为

(CO):

) = 1:1、温度为260 ℃、压力为2 MPa和空速为6000 mL/(g·h)的条件下反应72 h评价了催化剂催化生成C

烃类的性能。结果表明，浸渍法所得CZA-ZrO

(im)的表面ZrO

与CuZnAl产生了强相互作用且表面酸碱性适宜，有利于在CuZnAl上生成CH

O*等物种，并在ZrO

作用下生成C

烃类异构体。CZA-ZrO

(im)的CO转化率、C

烃类选择性和C

烃类异构体在C

烃类中的占比（物质的量分数）分别为5.9%、15.1%和79.7%。

Abstract

Heterogeneous synthesis is the reaction for direct synthesis of isobutene and isobutane from syngas (CO + H

). Currently

the reaction is performed using ZrO

-based catalysts

but the reaction conditions are generally harsh and the catalysts have low CO conversion rate and C

hydrocarbon selectivity. In order to solve the problem of weak performance of CO activation to generate C1 species of single ZrO

the bifunctional catalyst

s formed by coupling CuZnAl catalyst with ZrO

were investigated. The bifunctional catalysts were prepared by co-precipitation

impregnation and physical mixing methods

respectively

and their texture properties

oxide mass fractions and crystalline phase structures were characterized. The performances of catalysts for production of C

hydrocarbons were evaluated under syngas composition of

(CO):

) = 1:1

temperature of 260 ℃

pressure of 2 MPa and space velocity of 6000 mL/(g·h) for 72 h. The results show that the surface ZrO

of CZA-ZrO

(im) obtained by impregnation method produced strong interaction with CuZnAl

and the surface of CZA-ZrO

(im) has suitable acidity and alkalinity

which were favorable for generating CH

O* species on CuZnAl

and generating C

hydrocarbon isomers under the action of ZrO

. The CO conversion rate

hydrocarbon selectivity and the proportion (mole fraction) of C

hydrocarbon isomers in C

hydrocarbons are 5.9%

15.1% and 79.7%

respectively.

关键词

Keywords

references

CHEN Y P , WEI J T , DUYAR M S , et al . Carbon-based catalysts for Fischer-Tropsch synthesis [J ] . Chemical Society Reviews , 2021 , 50 ( 4 ): 2337 - 2366 .

徐振刚 , 陈亚飞 . 我国煤化工的技术现状与发展对策 [J ] . 煤炭科学技术 , 2007 , 35 ( 8 ): 6 - 12 .

XU Z G , CHEN Y F . Present status of coal chemical technology in China and development countermeasures [J ] . Coal Science Technology , 2007 , 35 ( 8 ): 6 - 12 .

JIAO J Q , LIU C Q , ZHANG G H , et al . Advances in catalysts for the one-step preparation of aromatics by bifunctional catalytic route from syngas [J ] . Fuel , 2025 , 385 : 134118 .

MUNDER B , RIHKO-STRUCKMANN L , SUNDMACHER K . Steady-state and forced-periodic operation of solid electrolyte membrane reactors for selective oxidation of n -butane to maleic anhydride [J ] . Chemical Engineering Science , 2007 , 62 ( 18/19/20 ): 5663 - 5668 .

ZHANG T , LI X , SUN J C , et al . One-step synthesis of 1,4-butanediol from maleic anhydride by gas-phase selective hydrogenation over x Re/CuZnZr catalysts [J ] . Journal of Catalysis , 2024 , 433 : 115469 .

MAGAJI S , HUSSAIN I , MALAIBARI Z , et al . Catalytic cracking of liquefied petroleum gas (LPG) to light olefins using zeolite-based materials: Recent advances, trends, challenges and future perspectives [J ] . The Chemical Record , 2024 , 24 ( 11 ): e202400110 .

WANG P , CHIANG F K , CHAI J C , et al . Efficient conversion of syngas to linear α -olefins by phase-pure χ -Fe 5 C 2 [J ] . Nature , 2024 , 635 ( 8037 ): 102 - 107 .

王野 , 康金灿 , 张庆红 . 费托合成催化剂的研究进展 [J ] . 石油化工 , 2009 , 38 ( 12 ): 1255 - 1263 .

WANG Y , KANG J C , ZHANG Q H . Research advances in catalysts for Fischer-Tropsch synthesis [J ] . Petrochemical Technology , 2009 , 38 ( 12 ): 1255 - 1263 .

MARUYA K I , KOMIYA T W S , HAYAKAWA T , et al . Active sites on ZrO 2 for the formation of isobutene from CO and H 2 [J ] . Journal of Molecular Catalysis A—Chemical , 2000 , 159 : 97 - 102 .

LU L H , HAYAKAWA T , UEDA T , et al . Dependence of catalytic activity in CO hydrogenation on strong basic sites of ZrO 2 surface [J ] . Chemistry Letters , 1998 ( 1998 ): 65 - 66 .

MÜLLER M , KUTSCHERAUER M , BÖCKLEIN S , et al . On the importance of by-products in the kinetics of n -butane oxidation to maleic anhydride [J ] . Chemical Engineering Journal , 2020 , 401 : 126016 .

KIM D , YUN H , KIM J , et al . Enhanced C—C coupling of Cu-based catalysts via zirconia-driven carbonate interaction for electrochemical CO 2 reduction reaction [J ] . Journal of Materials Chemistry A , 2024 , 12 ( 35 ): 23780 - 23788 .

ZHANG C H , YANG Y , TENG B T , et al . Study of an iron-manganese Fischer-Tropsch synthesis catalyst promoted with copper [J ] . Journal of Catalysis , 2006 , 237 ( 2 ): 405 - 415 .

CHENG S Y , KOU J W , GAO Z H , et al . Preparation of complexant-modified Cu/ZnO/Al 2 O 3 catalysts via hydrotalcite-like precursors and its highly efficient application in direct synthesis of isobutanol and ethanol from syngas [J ] . Applied Catalysis A: General , 2018 , 556 : 113 - 120 .

GAO P , LI F , XIAO F K , et al . Effect of hydrotalcite-containing precursors on the performance of Cu/Zn/Al/Zr catalysts for CO 2 hydrogenation: Introduction of Cu 2+ at different formation stages of precursors [J ] . Catalysis Today , 2012 , 194 ( 1 ): 9 - 15 .

JEONG H , KIM K I , KIM T H , et al . Hydrogen production by steam reforming of methanol in a micro-channel reactor coated with Cu/ZnO/ZrO 2 /Al 2 O 3 catalyst [J ] . Journal of Power Sources , 2006 , 159 ( 2 ): 1296 - 1299 .

武雪梅 , 谭明慧 , 耿海伦 , 等 . ZrO 2 晶型对CO加氢制异丁烯反应影响的研究 [J ] . 燃料化学学报（中英文） , 2023 , 51 ( 4 ): 473 - 481 .

WU X M , TAN M H , GENG H L , et al . Effect of crystal structure of ZrO 2 catalyst on isobutene synthesis from CO hydrogenation [J ] . Journal of Fuel Chemistry and Technology , 2023 , 51 ( 4 ): 473 - 481 .

MCTAGGART F . Reduction of zirconium and hafnium oxides [J ] . Nature , 1961 , 191 ( 4794 ): 1192 - 1192 .

GONG N N , ZHANG T , TAN M H , et al . Realizing and revealing complex isobutyl alcohol production over a simple Cu-ZrO 2 catalyst [J ] . ACS Catalysis , 2023 , 13 ( 6 ): 3563 - 3574 .

CUI G Q , ZHANG X , WANG H , et al . ZrO 2 - x modified Cu nanocatalysts with synergistic catalysis towards carbon-oxygen bond hydrogenation [J ] . Applied Catalysis B: Environmental , 2021 , 280 : 119406 .

CHEN H , CUI H S , LV Y , et al . CO 2 hydrogenation to methanol over Cu/ZnO/ZrO 2 catalysts: Effects of ZnO morphology and oxygen vacancy [J ] . Fuel , 2022 , 314 : 123035 .

LI C M , FUJIMOTO K . Selective synthesis of isobutane from CO 2 -containing synthesis gas [J ] . Energy & Fuels , 2014 , 28 ( 2 ): 1331 - 1337 .

SUN J M , ZHU K K , GAO F , et al . Direct conversion of bio-ethanol to isobutene on nanosized Zn x Zr y O z mixed oxides with balanced acid-base sites [J ] . Journal of the American Chemical Society , 2011 , 133 ( 29 ): 11096 - 11099 .

DING J , JIANG R J , HU S , et al . Enhanced selectivity to methanol in CO 2 hydrogenation on CuO/ZrO 2 catalysts by alkali metal modification [J ] . ChemCatChem , 2025 , 17 ( 2 ): 202401400 .

王竟荣 , 高志华 , 黄伟 . 沉淀剂对CuZnAl催化剂催化CO加氢合成C 2+ 醇性能的影响 [J ] . 石油学报（石油加工） , 2021 , 37 ( 3 ): 498 - 507 .

WANG J R , GAO Z H , HUANG W . Effect of precipitants on the performance of CuZnAl catalyst in CO hydrogenation to C 2+ OH [J ] . Acta Petrolei Sinica (Petroleum Processing Section) , 2021 , 37 ( 3 ): 498 - 507 .

XIA S X , NIE R F , LU X Y , et al . Hydrogenolysis of glycerol over Cu 0.4 /Zn 5.6- x Mg x Al 2 O 8.6 catalysts: The role of basicity and hydrogen spillover [J ] . Journal of Catalysis , 2012 , 296 : 1 - 11 .

RAHMATMAND B , RAHIMPOUR M R , KESHAVARZ P . Introducing a novel process to enhance the syngas conversion to methanol over Cu/ZnO/Al 2 O 3 catalyst [J ] . Fuel Processing Technology , 2019 , 193 : 159 - 179 .

TSENG S C , JACKSON N B , EKERDT J G . Isosynthesis reactions of CO and H 2 over zirconium dioxide [J ] . Journal of Catalysis , 1988 , 109 ( 2 ): 284 - 297 .

相宏伟 , 钟炳 , 彭少逸 . CO + H 2 在ZrO 2 催化剂上合成异构烃反应机理的研究 [J ] . 天然气化工—C1化学与化工 , 1994 , 19 ( 4 ): 14 - 19 .

XIANG H W , ZHONG B , PENG S Y . Study on isohydrocarbon synthesis reaction mechanism from ZrO 2 catalyst [J ] . Natural Gas Chemical Industry , 1994 , 19 ( 4 ): 14 - 19 .

SU C L , HE D H , LI J R , et al . Relationship between formation of DME, CH 3 OH and i -C 4 H 8 in isosynthesis [J ] . Studies in Surface Science and Catalysis , 2000 , 130 : 3735 - 3740 .

ZHANG R J , WANG K Z , XING Y Q , et al . Research advances on ZrO 2 -based catalysts for CO hydrogenation to isobutene [J ] . Fuel , 2025 , 380 : 133139 .

胡雅琴 . CO 加氢合成异丁烯研究进展 [J ] . 山西大同大学学报（自然科学版） , 2012 , 28 ( 6 ): 28 - 32 .

HU Y Q . Progressin synthesis of isobutenefrom CO hydrogenation [J ] . Journal of Shanxi Datong University (Nature Science) , 2012 , 28 ( 6 ): 28 - 32 .
